Neve 1073OPX & USB/ADAT Digital Card Bundle

Neve 1073OPX & USB/ADAT Digital Card Bundle

8-channel Mic Preamp

£4,194.00 (Inc VAT)

£3,495.00 (Ex VAT). Shipping calculated at checkout.

Introducing the 1073OPX: Where Tradition Meets Innovation. Featuring eight remote-controllable 1073® preamps in a compact 2U rack, the 1073OPX combines classic sound with modern convenience for space-conscious studios. Key Features: 1. USB/ADAT Digital Option: Enhance your setup with...

Backorder, Available To Order

For more accurate delivery times, please click here.

Product Information
Shipping & Returns

Introducing the 1073OPX: Where Tradition Meets Innovation.

Featuring eight remote-controllable 1073® preamps in a compact 2U rack, the 1073OPX combines classic sound with modern convenience for space-conscious studios.

Key Features:

1. USB/ADAT Digital Option: Enhance your setup with the optional 1073OPX USB/ADAT Card. It offers two modes:
• USB/ADAT Hub mode: Expands the 1073OPX into a USB Audio Interface, supporting up to 16 inputs and 10 outputs through a single USB connection.
• ADAT standalone mode: Digitally expands ADAT-compatible interfaces using optical connections, adding eight 1073 preamps and stereo output.

2. Remote Control: The 1073OPX app enables remote control of switch settings, gain, and routing. Ideal for modern studios, live venues, and broadcast setups. Control up to eight OPX units for 64 remote-controlled preamps.

3. USB/Dante AD/DA Conversion: With the optional 1073OPX USB/Dante Card (sold separately), experience premium AD/DA conversion up to 192kHz for all eight preamps. Dual ethernet ports offer redundancy in Dante networks, while USB 2.0 connection turns the preamp into a complete studio interface.

4. Marinair® Transformers: Employing patented Marinair® transformers ensures unmatched preamp quality and tone across the eight microphone inputs.

5. 1dB Stepped Gain: Achieve ultimate accuracy with 1dB stepped gain control, perfect for stereo pairs and instrument groups through local or remote adjustments.

6. Mic, Line, DI Inputs: Versatile inputs for microphone, line, and instrument sources with separate gain settings, tailored for modern recording setups.

7. Class A DI: Unique class-A design and FET transistor in the instrument DI deliver musical coloration and high performance.

8. Smart Switch Controls: Intelligent phantom power circuit supplies +48v to microphone inputs only. PAD switch offers -25dB attenuation, and 180-degree phase flip aids multi-microphone setups. An 80Hz 12dB/Octave filter cuts unwanted bass frequencies.

9. Lo Z Impedance: Toggle between 1.2kOhms and 300Ohms to optimize preamp impedance for any microphone type.

10. Front & Rear Connections: Dual input connections with independent switching allow seamless integration into studio racks without the need for re-patching.

11. Monitoring & Summing: Analog and digital monitor paths connect to loudspeakers with headphone monitoring. Preamp outputs can be routed to the monitor path for latency-free monitoring or summing.

Elevate your studio`s capabilities with the 1073OPX – the perfect blend of classic Neve sound and modern functionality.

General Specification

• 8 Channels of remote-controlled 1073® Mic/Line/Instrument Preamplifiers.
• Exclusive Neve® Marinair® transformers on Microphone input.
• Class-A transformer-less DI input
• Remote control software can control up to eight 1073OPX racks at a time (64 preamps!)
• Automatic Total Recall™ of all settings.
• Front Mic/Line combi input
• Rear Mic/Line D-Type connection
• 80Hz High pass filter
• -25dB pad
• Phase flip
• Smart Phantom Power control
• Hi/Lo Impedance selector from 300Ω to 1.3KΩ
• Separate stereo monitor path with Independent level control
• Latency-free monitoring of all signal sources
• Eight front D.I inputs for instrument tracking
• Front-mounted Headphone output
• Heat Dissipation 40 Watts
• Input voltage range 90-240V

Digital Card (optional add on) General Specification
• USB connection for use as standalone primary audio interface/core audio device.
• Dante Primary and Secondary connection for Audio-over-IP application.
• Word Clock Sync In/Out
• Selectable Headroom from +18, +24, +26dB

Audio Performance
• Headroom: <+26dBu @ 1kHz (<0.5% THD+N)
• Frequency Response: Typically +/-0.15dB, 20Hz to 20kHz
• Distortion (THD+N): Typically 0.002% @ 1kHz (measured at +20dBu, 10Hz to 80kHz filter)
• General Noise: <-85dBu (20Hz to 22kHz filter)
• Mic EIN Noise: Typically -125dBu (20Hz to 20kHz)
• Microphone Inputs: Input Impedance ≈300Ω or ≈1.3kΩ (PAD out). Transformer coupled. Gain 20dB to 70dB in 1dB steps
• Line Inputs: Input Impedance ≈10kΩBridging(PAD out). Gain -20dB to +20dB in 1dB steps
• DI Inputs: Input Impedance <650kΩ. Transformer-less Class A Gain 30dB to 60dB in 1dB steps

AD/DA Card Specification
• Noise: > -118dBFS
• Dynamic Range: 120dB
• Distortion: <0.0007%
• RTL: 4.01ms (192kHz, 32 buffer)

Dimensions
• Height: 177mm/7 inches (2U)
• Width: 484mm/19.05 inches (19″ rack)
• Depth: 360mm/14.17 inches
• Weight: 7.8Kg
