Neve 1073 DPA

1073DPA

The Essential Studio Preamp

The 1073DPA provides two Class A Neve® 1073® microphone preamplifiers in single rack space, without the additional EQ found on the classic 1073 unit – offering the very essence of the legendary 1073 sound.

Marinair® Transformers
Exclusive Marinair® transformers are used on the input and output stage to produce that classic 1073® sound.

Class A Discrete
The 1073DPA retains the discrete, class-A topology made famous by the classic 1073. The discrete audio path is constructed using through-hole methods, including mounting the Marinair® transformers and class-A transistor-based amplifiers.

Unique 1073 Gain Staging
The classic 5dB stepped Elma switch delivers accurate gain levels throughout the gain range. This unique layout means there is no need for a mic/line switch as the pot itself selects the preamp and input. Three distinct gain stages provided by two independent transistor-based preamplifiers provide gain for any DI, line input or microphone signal.

High Output - Harmonic Saturation
The 1073® preamp produces up to 80dB of microphone gain. By combining multiple gain stages and utilising the output trim control, the 1073DPA can be driven hard, bringing out the musical drive and harmonic saturation for which the 1073 is famous.

Lo-Z Impedance
The 1073DPA impedance can be optimised for use with a wide range of modern or vintage microphones, with quickly selectable settings of 1.2kΩ and 300Ω.

Phase Invert
The 180-degree phase flip feature is handy in multi-microphone setups with multiple preamps, ideal for top and bottom snare micing.

General Specification
